Python+OpenCV实现车牌字符分割和识别

import cv2

# 1、读取图像，并把图像转换为灰度图像并显示
img = cv2.imread("chepai/6.png") # 读取图片
img_gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY) # 转换了灰度化
cv2.imshow('gray', img_gray) # 显示图片
cv2.waitKey(0)

# 2、将灰度图像二值化，设定阈值是100
img_thre = img_gray
cv2.threshold(img_gray, 100, 255, cv2.THRESH_BINARY_INV, img_thre)
cv2.imshow('threshold', img_thre)
cv2.waitKey(0)

# 3、保存黑白图片
cv2.imwrite('thre_res.png', img_thre)

# 4、分割字符
white = [] # 记录每一列的白色像素总和
black = [] # ..........黑色.......
height = img_thre.shape[0]
width = img_thre.shape[1]
white_max = 0
black_max = 0
# 计算每一列的黑白色像素总和
for i in range(width):
 s = 0 # 这一列白色总数
 t = 0 # 这一列黑色总数
 for j in range(height):
 if img_thre[j][i] == 255:
  s += 1
 if img_thre[j][i] == 0:
  t += 1
 white_max = max(white_max, s)
 black_max = max(black_max, t)
 white.append(s)
 black.append(t)
 print(s)
 print(t)

arg = False # False表示白底黑字；True表示黑底白字
if black_max > white_max:
 arg = True

# 分割图像
def find_end(start_):
 end_ = start_+1
 for m in range(start_+1, width-1):
 if (black[m] if arg else white[m]) > (0.95 * black_max if arg else 0.95 * white_max): # 0.95这个参数请多调整，对应下面的0.05
  end_ = m
  break
 return end_

n = 1
start = 1
end = 2
while n < width-2:
 n += 1
 if (white[n] if arg else black[n]) > (0.05 * white_max if arg else 0.05 * black_max):
 # 上面这些判断用来辨别是白底黑字还是黑底白字
 # 0.05这个参数请多调整，对应上面的0.95
 start = n
 end = find_end(start)
 n = end
 if end-start > 5:
  cj = img_thre[1:height, start:end]
  cv2.imshow('caijian', cj)
  cv2.waitKey(0)
